Best Single Beam Nonwoven Equipment
| 1600M S system | |
| Width of finished fabric: | 1600mm |
| Single filament titer: | 2. 0-2. 5 denier |
| Daily output: | 4-5MT/Day based on 40gsm (guarantee the quality as both side agreement) |
| Web weight: | 9-150 g/m2 |
| GSM Variation: | CV value less than 6 % |
| Extruder size: | φ150×33: 1 |
- Description of Nonwoven machine
- Specifications
- Applications
- Advantage
Description of Nonwoven machine
Zhejiang Yanpeng Non-woven Machinery Co.,Ltd is a professional non-woven production line manufacturer which engaged in development and production for many years.
Backed by the support of our dexterous workforce, our company is known as the leading manufacturer and exporter of Non Woven equipment. Developed in compliance with industrial standards using advanced techniques, these plants are corrosion resistant and reckoned for their robust construction and excellent durability. Extensively used to weave different lengths and colors of fabrics; we are offering these plants in different technical specifications. Furthermore, we duly check our Non Woven equipment on regular intervals to avoid any kind of defect.
Specifications
| 1600M S system | |
| Width of finished fabric: | 1600mm |
| Single filament titer: | 2. 0-2. 5 denier |
| Daily output: | 4-5MT/Day based on 40gsm (guarantee the quality as both side agreement) |
| Web weight: | 9-150 g/m2 |
| GSM Variation: | CV value less than 6 % |
| Extruder size: | φ150×33: 1 |
| Mechanical speed：10-150 | |
| Process speed: | 10~120m/min |
| Power requirement: | Loading 350kva Actually 210kva. |
| Space requirement: | 15*10*11m |
| No. of spin beams: | 1 set |
Working process flow
Feeding→Extrusion Melting→filtering→metering→spinning→Cooling→Stretching
→Web spreading→Thermal bonding→slitting→collecting
Applications
Nonwoven fabrics are engineered fabrics that may be a limited life, single-use fabric or a very durable fabric. Nonwoven fabrics provide specific functions such as absorbency, liquid repellence, resilience, stretch, softness, strength, flame retardant, washable, cushioning, filtering, use as a bacterial barrier and sterility. These properties are often combined to create fabrics suited for specific jobs, while achieving a good balance between product use-life and cost. They can mimic the appearance, texture and strength of a woven fabric and can be as bulky as the thickest paddings. In combination with other materials they provide a spectrum of products with diverse properties, and are used alone or as components of apparel, home furnishings, health care, engineering, industrial and consumer goods.
Certificate
ISO9001, CE Certificate, SGS Certificate
Advantage
After-sales service
Installation:
The seller will send 2 or 4 engineers to install, test the production line and train customers’ workers in buyers’ factory. It will take 1 month for whole installation and training.
The buyer should cover engineers’ salary and visa cost. And the buyer should cover Round air tickets, accommodations, transportation in buyers’ country, food, medical care, safety cost, and related cost happens in buyers’ country. Also, the buyer should prepare enough labor, electric wire outside the control panel and tools for installations.
Guarantee:
Guarantee period for the delivered equipment will be 12month after completion of erection but not later than 18months after shipment. In case any item proves to be defective and the damage is confirmed by seller’s technicians within this period, the seller will at their choice either send engineer to repair or supply a new one for replacement free of charge on the basis of CNF delivery.
The above item does not include the parts, which have regular spares or the parts damaged from normal wear, abnormal operation, improper maintenance and inadequate civil works. The seller is not liable for any production loss under any circumstances.
Packing
As per export standard, they will also be treated before delivery against damage and rusting.
