High Quality Single Beam Nonwoven Equipment
| Technical Parameters (Standard Specification)of Our Non-woven Machine | |||||
| Model No. | Gram Weight(g/sq. m) | Max Speed(m/min. ) | Capacity(T/Days) | Equipment Size | |
| YP-S(single beam) | 1. 6M | 10-180 | 200 | 4 | 15*8. 6*9. 5m |
| 2. 4M | 10-180 | 200 | 7-8 | 15*9*9. 5m | |
| 3. 2M | 10-180 | 200 | 9-10 | 15*10*9. 5m | |
- Description of Nonwoven machine
- Specifications
- Applications
- Advantage
Description of Nonwoven machine
Zhejiang Yanpeng Non-woven Machinery Co.,Ltd is a professional non-woven production line manufacturer which engaged in development and production for many years.
The former of the company is Wenzhou Yanpeng non-woven technology Co.,Ltd.
Our company has focused on making non-woven production line since 2003, We can provide customized single S, double S three S spunbond non-woven production line,
SSMS, SMMS SMS spunmelt (spunbond & meltblown) production lines,and other PP,PET, BiCo spunbond production line to our customers.
Our company has already passed ISO9001:2010 international quality management system certification , standardization certification, CE certification, and we also have the right of import and export.
What is nonwoven fabric
Nonwoven fabrics are broadly defined as sheet or web structures bonded together by entangling fibre or filaments (and by perforating films) mechanically, thermally or chemically. They are flat, porous sheets that are made directly from separate fibres or from molten plastic or plastic film. Typically, certain percentage of recycled fabrics may be used in nonwoven fabrics. The percentage of recycled fabrics varies based upon the strength of material needed for the specific use. Conversely, some nonwoven fabrics can be recycled after use, given proper treatment and facilities. For this reason, some consider nonwovens a more ecological fabric for certain applications, especially in fields and industries where disposable or single use products are important, such as hospitals, schools, nursing homes and luxury accommodations.
Specifications
S system
| Width of finished fabric: | 1600mm/2400mm/3200mm |
| Single filament titer: | 2. 0-2. 5 denier |
| Daily output: | 4-10MT/Day based on 40gsm (guarantee the quality as both side agreement) |
| Web weight: | 9-150 g/m2 |
| GSM Variation: | CV value less than 6 % |
| Extruder size: | φ150×33: 1 |
| Mechanical speed：10-150 | |
| Process speed: | 10~120m/min |
| Power requirement: | Loading 350kva Actually 210kva. |
| Space requirement: | 15*10*11m |
| No. of spin beams: | 1 set |
Applications
Certificate
ISO9001, CE Certificate, SGS Certificate
Working process flow
Feeding→Extrusion Melting→filtering→metering→spinning→Cooling→Stretching
→Web spreading→Thermal bonding→slitting→collecting
Advantage
After-sales service
Installation
The seller will send 2 or 4 engineers to install, test the production line and train customers’ workers in buyers’ factory. It will take 1 month for whole installation and training.
The buyer should cover engineers’ salary and visa cost. And the buyer should cover Round air tickets, accommodations, transportation in buyers’ country, food, medical care, safety cost, and related cost happens in buyers’ country. Also, the buyer should prepare enough labor, electric wire outside the control panel and tools for installations.
Guarantee
Guarantee period for the delivered equipment will be 12month after completion of erection but not later than 18months after shipment. In case any item proves to be defective and the damage is confirmed by seller’s technicians within this period, the seller will at their choice either send engineer to repair or supply a new one for replacement free of charge on the basis of CNF delivery.
The above item does not include the parts, which have regular spares or the parts damaged from normal wear, abnormal operation, improper maintenance and inadequate civil works. The seller is not liable for any production loss under any circumstances.
Packing
As per export standard, they will also be treated before delivery against damage and rusting.
Packing & Transportation
