Single Beam Nonwoven Production Line
| Model No. | YP-S-1. 6 | YP-S-2. 4 | YP-S-3. 2 |
| Width | 1. 6METER | 2. 4METER | 3. 2METER |
| Whole Line Size | 15*8. 6*9. 5m | 15*9*9. 5m | 15*10*9. 5m |
| Speed | 150M/MIN | 150M/MIN | 150M/MIN |
| GSM | 10-180G/MIN | 10-180G/MIN | 10-180G/MIN |
| Capacity | 4T/DAY | 7-8TON/DAY | 9-10TON/DAY |
| Embossing Pattern | Diamond, oval, cross or line | Diamond, oval, cross or line | Diamond, oval, cross or line |
- Description of Nonwoven machine
- Specifications
- Applications
- Advantage
Description of Nonwoven machine
Yanpeng Nonwoven production line
This single beam nonwoven production line is using polypropylene (PP) as raw material, under several processing, to get non-woven fabric material finally. This production line is including feeding system, screw extrution, filter, metering pumps, spinning box, cooling system, stretcher.
The nonwoven fabric is mainly used in Package, household, Hygiene industries. But single beam Nonwoven production line is usually for package,like nonwoven bag.
Specifications
| Product name: | Single beam Nonwoven production line |
| Final products: | PP spun bond Nonwoven Fabric |
| Width: | 1600-3200MM or Customized |
| Raw material: | Polypropylene |
| Capacity: | 4-10 Tons/day |
| Application: | Nonwoven Fabric Disposable |
| Color: | As customer required |
| After-sales Service Provided: | Engineers available to service machinery overseas |
| Certificate: | CE, ISO |
| Machine Type: | Nonwoven Fabric Production line |
| Condition: | New Automatic |
| Grade: | Automatic |
Applications
Nonwoven Fabric Applications
Yanpeng Nonwoven production lines are designed and manufactured in following applications. The application is correspondingly wide.
Such as
● PACKAG: Shopping bag, Rice Packaging, Clothes packaging, etc.
● HYGIENE: Baby and adult diapers, Female hygiene, etc.
● MEDICAL: Surgeon's masks, Disposable garments, etc.
● HOUSEHOLD: Suit Cover, Knitwear Cover, Garderobe Cover, Table Cloth Etc.
● FILTRATION: Air, Gas, Liquids, etc.
Advantage
1. Quality Control in whole process, provide individual high cost-effective single beam nonwoven production lines, helping customer cost saving.
2. Focus on nonwoven production lines research and development for 16 years. Install and running more than 400 lines all over the world.
3. Import high precision CNC machine from Japan. The key parts machining in house, ensure to provide high quality machine for each customer.
4. Over 20 person team for machine after sales service.Ensure the customers can get quickly and professional installation and debugged in time.
Certificate
Packing & Transportation
