Single Beam Spunbond Nonwoven Production Line
| Model No. | YP-S-1. 6 | YP-S-2. 4 | YP-S-3. 2 |
| Width | 1. 6METER | 2. 4METER | 3. 2METER |
| Whole Size | 15*8. 6*9. 5m | 15*9*9. 5m | 15*10*9. 5m |
| Speed | 150M/MIN | 150M/MIN | 150M/MIN |
| GSM | 10-180G/MIN | 10-180G/MIN | 10-180G/MIN |
| Capacity | 4T/DAY | 7-8TON/DAY | 9-10TON/DAY |
| Embossing Pattern | Diamond, oval, cross or line | Diamond, oval, cross or line | Diamond, oval, cross or line |
- Description of Nonwoven machine
- Specifications
- Applications
- Advantage
Description of Nonwoven machine
We started in Nonwoven fabric machinery production since 2003, during
the years, we have manufactured and set up more than 400 lines in the
domestic and oversea market.
We delicated in supply the
turnkey solution in nonwoven fabric making machine. We keep making
improvement and development to provide turn key solution for our
customer.
The process as follow
Polymer
(polypropylene + recycling) - high temperature melt extrusion of large
screw - Filter - metering pump (quantitative conveying) - spinning
(drawing up and down the spinning entrance) - cooling - Air traction -
screen forming - up and down pressure rollers (pre-reinforcement) - hot
rolling (reinforcement) - winding - inverted distribution
Cutting-Weighing Packaging-Storage of Finished Products
Specifications
| Product name: | Single beam Spunbond Nonwoven fabric production line |
| Final products: | PP spun bond Nonwoven Fabric |
| Width: | 1600-3200MM or Customized |
| Raw material: | Polypropylene |
| Capacity: | 4-10 Tons/day |
| Application: | Nonwoven Fabric Disposable |
| Color: | As customer required |
| After-sales Service Provided: | Engineers available to service machinery overseas |
| Certificate: | CE, ISO |
| Machine Type: | Nonwoven Fabric Production line |
| Condition: | New Automatic |
| Grade: | Automatic |
Applications
Yanpeng Nonwoven fabric production lines are designed and manufactured in following applications. Mainly the single beam machine is widely used in package industry. The application is correspondingly wide.
Such as
● PACKAG: Non woven shopping bag, Rice Packaging, Clothes packaging, etc.
● HYGIENE: Baby and adult diapers, Female hygiene, etc.
● MEDICAL: Surgeon's masks, Disposable garments, etc.
● HOUSEHOLD: Suit Cover, Knitwear Cover, Garderobe Cover, Table Cloth Etc.
● FILTRATION: Air, Gas, Liquids, etc.
Advantage
Our team and service
1. Quality Control in whole process, provide individual high cost-effective nonwoven fabric production lines, helping customer cost saving.
2. Focus on nonwoven fabric production line research and development for 16 years. Install and running more than 400 lines all over the world.
3. Import high precision CNC machine from Japan. The key parts machining in house, ensure to provide high quality machine for each customer.
4. Over 20 person team for machine after sales service.Ensure the customers can get quickly and professional installation and debugged in time.
Certificate
Packing & Transportation
