SS Non woven Production Line

Home > Product > PP Spunbond Non woven Production Line > SS Non woven Production Line

double-beams-nonwoven-machine
46
44
42
double-beams-nonwoven-machine
46
44
42

Double Beams Nonwoven Machine


Model No.YP-SS-1. 6YP-SS-2. 4YP-SS-3. 2
SS(Product width)1600mm2400mm3200mm
Equipment Size29*13*10m30*14*10m32*15*10m
Speed350m/min350m/min350m/min
Gram Weight10-150g/m210-150g/m210-150g/m2
Yield (according to 20g/m2)9-10T/Days13-14T/Days18-19T/ Days
  • Description of Nonwoven machine
  • Specifications
  • Applications
  • Advantage
Description of Nonwoven machine

Product Details

Place of Origin:Wenzhou, Zhejiang
Brand Name:YP(YanPeng)
Model Number:YP-SS 1600mm, 2400mm, 3200mm
Certification:CE/ISO9001

Payment & Shipping Terms

Minimum Order Quantity:1SET
Delivery Time:120Days
Payment Terms:T/T, L/C, D/P
Supply Ability:50 sets per year

Details Description

PP Double beams Nonwoven machine for making nonwoven fabric rolls.

This machine is polypropylene nonwoven fabric machine. Its raw material is polypropylene(PP), take the principle of spinning  fibres, during polymer filature, continuous filament is extended into fiber, during which is finished by mechanical hot pressing.



Specifications

Model No.YP-SS-1. 6YP-SS-2. 4YP-SS-3. 2
SS(Product width)1600mm2400mm3200mm
Equipment Size29*13*10m30*14*10m32*15*10m
Speed350m/min350m/min350m/min
Gram Weight10-150g/m210-150g/m210-150g/m2
Yield (according to 20g/m2)9-10T/Days13-14T/Days18-19T/ Days

Process Flow

Feeding→Extrusion Melting→filtering→metering→spinning→Cooling→Stretching→Web spreading→Thermal bonding→slitting→collecting

Applications

Nonwoven machine is used to produce nonwoven fabrics, fully automatic and convenient operation.Nonwoven machine can be customized according to customer needs.

Yanpeng PP double beams Nonwoven machines are designed and manufactured in accordance with individual customers requirements. Their possible area of application is correspondingly wide.

Such as

Package, hygiene, medical, furniture, technical, filtration.

Double beams nonwoven machine is usually used in the package and furniture, such as shopping bags or bed covers.

In addition, this nonwoven machine can produce non-woven fabrics of different colors, differen grams, different lines according to users'demand.

Advantage



1. We provide  pre-sales,  sales and after sales service, especially one year of free maintenance warranty.

2. If there are problems with the nonwoven machine parts, customer can take pictures and send to us by email to explain the situation, we will help to solve it on line or by email as soon as possible.

3. We will send 2 or 4 engineers to install, test the production line and train customers’ workers in buyers’ factory. It will take 1 month for whole installation and training.

4. If there are big problems of the nonwoven machine caused by wrong operation, we will arrange professional engineer to solve the problem in customer's factory, but all the cost including visa, air fare and accommodations must be paid by customer.
