2025 latest Best sale SMSMS melt blown non-woven production line
| Model No. | YP-SSMMS-1.6 | YP-SSMMS-2.4 | YP-SSMMS-3.2 |
| Product Width | 1600mm | 2400mm | 3200mm |
| Equipment Size | 70*26*11m | 70*28*11m | 70*30*11m |
| Machine Speed | 600m/min | 600m/min | 600m/min |
| Gram Weight | 12~70g/m² | 12~70g/m² | 12~70g/m² |
| Capacity (according to 40g/m²) | 13-14ton/day | 20-21ton/day | 29-30ton/day |
- Description of Nonwoven machine
- Specifications
- Applications
- Advantage
Description of Nonwoven machine
● Power(W): 250-415KW
● Dimension(L*W*H): 70*26*11M
● Weight: 18-100ton
● Warranty: 1 Year
● After-sales Service Provided: Video technical support, Field installation, commissioning and training, Field maintenance and repair service, Engineers available to service machinery overseas
● Condition: New
● Automatic Grade: Automatic
● Place of Origin: Zhejiang, China (Mainland)
● Brand Name: YANPENG
● Voltage: Customized
● Certification: CE/ISO9001
● Product name: PP Spunbond Nonwoven Fabric Machine
● Product width: 1.6M/2.4M/3.2M
● Embossing pattern: Diamond, Oval, Cross, Line
● Model Number:SSMMS
● Speed: 600m/min
● Gram weight: 12-70g/m2
● Output: 13-14T/Days or 20-21T/Days or 29-30T/Days
Specifications
Feeding:
Raw material: Polypropylene Raw material
1.During feeding, there should be no hard objects such as metals, and no water to ensure cleanliness. 2. Material shortage: Fan malfunction, filter blockage, pipeline leakage, injection machine malfunction alarm. 3. Suction machine: using a volumetric method, simply input the desired percentage.
2.Function of spinning box:
A insulation function
B serves as the base for spinning components
C ensures that the melt pressure is uniform and the flow rate reaches the spinneret uniformly
| M main process system | YP-SSMMS-1.6M | YP-SSMMS-2.4M | YP-SSMMS-3.2M |
| RawMaterial | 2 sets | ||
| Extruder | 2 sets | ||
| Filter | 2 sets | ||
| Spin pump | 2 sets | ||
| Meltblown Die | 2 sets | ||
| After special treatment | anti-static, anti-alcohol, anti-plasma, water-repellent, and hydrophilic properties | ||
Applications
Home and personal care: SSMMS non-woven fabric is used for bedding and interior decoration due to its softness, durability, and ease of cleaning.It is also used in baby diapers, diaper changing pads, and bibs due to its soft and hypoallergenic properties.
Filtration:SSMMS non-woven fabric is used for air filtration applications, including HVAC filters and respirators, due to its excellent filtration efficiency. It is also used in liquid filtration systems, such as water and oil filtration.
Advantage
1）Customized to your needs
2）Professional technical and after-sales team
3）No.1 domestic share of market
4）650+ nonwoven production lines experience
5）PLC controlled, operated with touch-screen, highly automatic and easy to operate
6）Independently R&D and manufacture core parts such as spinning components, quenching and drawing system, diffuser, web former, etc
7）Control elements are made by well-known brand, high performance and reliable technologies
