2400mm SSMMS efficient and stability spunbond non woven fabric making machine

Model No.	YP-SSMMS-1.6	YP-SSMMS-2.4	YP-SSMMS-3.2
Product Width	1600mm	2400mm	3200mm
Equipment Size	702611m	702811m	703011m
Machine Speed	600m/min	600m/min	600m/min
Gram Weight	12~70g/m²	12~70g/m²	12~70g/m²
Capacity (according to 40g/m²)	13-14ton/day	20-21ton/day	29-30ton/day

Inquiry

Description of Nonwoven machine
Specifications
Applications
Advantage

Description of Nonwoven machine

Yanpeng 1600mm SSMMS efficient and stability spunbond non woven fabric making machine.

This polypropylene(pp) spunbond nonwoven production line has advantages of superior performance, beautiful color, and good quality.

It can form a fibre web symmetrically and is complete in types. It also has material recycle unit to reduce the cost of products.

workshop3

Specifications

Feeding→Extrusion Melting→filtering→metering→spinning→Cooling→Stretching
→Web spreading→Thermal bonding→slitting→collecting

SSMMS

Feeding:
Raw material: Polypropylene Raw material
1.During feeding, there should be no hard objects such as metals, and no water to ensure cleanliness. 2. Material shortage: Fan malfunction, filter blockage, pipeline leakage, injection machine malfunction alarm. 3. Suction machine: using a volumetric method, simply input the desired percentage.

2.
Function of spinning box:

A insulation function

B serves as the base for spinning components

C ensures that the melt pressure is uniform and the flow rate reaches the spinneret uniformly

M main process system	YP-SSMMS-1.6M	YP-SSMMS-2.4M	YP-SSMMS-3.2M
RawMaterial	2 sets
Extruder	2 sets
Filter	2 sets
Spin pump	2 sets
Meltblown Die	2 sets
After special treatment	anti-static, anti-alcohol, anti-plasma, water-repellent, and hydrophilic properties

Applications

Medical and health field：Operating clothes, bed sheets, operating caps, protective clothing, disinfection bags, masks, diapers, women's sanitary napkins, baby diapers, adult slacks, pet urinals, pet pads non-woven fabrics, facial mask base cloth

Filtration:SSMMS non-woven fabric is used for air filtration applications, including HVAC filters and respirators, due to its excellent filtration efficiency. It is also used in liquid filtration systems, such as water and oil filtration.
