SSMS Non woven Production Line

Home > Product > PP Spunbond Non woven Production Line > SSMS Non woven Production Line

SSMS-2
SSMS-2

Newly designed SSMS meltblown nonwoven fabric making machine for medical supplies


Model No.YP-SSMS-1.6YP-SSMS-2.4YP-SSMS-3.2
Product Width1600mm2400mm3200mm
Equipment Size46*20*11m46*21*11m46*22*11m
Machine Speed400m/min400m/min400m/min
Gram Weight10~80g/m²10~80g/m²10~80g/m²
Capacity (according to 40g/m²)12-13ton/day19-20ton/day27-28ton/day

  • Description of Nonwoven machine
  • Specifications
  • Applications
  • Advantage
Description of Nonwoven machine

Our nonwoven fabric production line is used for the production of non woven fabrics through the process of PP melting, spinning, web forming, and thermal bonding. It primarily uses polypropylene (PP) as the main raw material, along with additives such as color masterbatch, antioxidants, anti-pilling agents, and flame retardants. The manufacturing facility can produce spunbond nonwoven materials of diverse colors and characteristics, catering to multiple usage scenarios.

Compared with SMS, SSMS has one more layer of spunbond fabric. Therefore it has better uniformity and more softer. It is widely used in the hygienic industry such as top sheet, core wrap, back sheet, and other components of diapers and sanitary napkins.




Specifications

Feeding→Extrusion Melting→filtering→metering→spinning→Cooling→Stretching
→Web spreading→Thermal bonding→slitting→collecting

Screw extruder Function:

1.Melt solid slices into a melt

2.Quantitatively output molten material under a certain head pressure

3.Compressing, exhausting, mixing, and materializing materials

Measurement section: Complete quantitative and extrusion, melt single-phase


M main process systemYP-SSMS-1.6MYP-SSMS-2.4MYP-SSMS-3.2M
RawMaterial1 sets
Extruder1 sets
Filter1 sets
Spin pump1 sets
Meltblown Die1 sets
After special treatmentanti-static, anti-alcohol, anti-plasma, water-repellent, and hydrophilic properties


Applications

Medical and health field:Operating clothes, bed sheets, operating caps, protective clothing, disinfection bags, masks, diapers, women's sanitary napkins, baby diapers, adult slacks, pet urinals, pet pads non-woven fabrics, facial mask base cloth


1. It has biocompatibility, does not contaminate the product, and prevents patients and medical staff from getting infected;

2. The material itself is non-toxic and does not contain harmful substances such as heavy metals;

3. High hydrostatic pressure, good protective and barrier properties; Has good anti-static, anti alcohol penetration, anti water penetration, antibody solution and blood penetration functions;

Advantage

Since from the beginning of 2008, we always focused on nonwoven equipment R&D and production. Until today,we serve over 200 customers at home and abroad. We help many customer achieve business success,such as in Mexico ,Colombia ,Pakistan, Russia,etc. We can help you from the factory layout plan to the non woven fabric marketing plan suggestion. We can providing useful factory running experience, etc.
