Highly Accurate SSS Spunbonded Composite Nonwoven Machine
| Model No. | YP-S-1.6 | YP-S-2.4 | YP-S-3.2 |
| Width | 1.6M | 2.4M | 3.2M |
| Size | 15*8.6*9.5m | 15*9*9.5m | 15*10*9.5m |
| Speed | 150m/min | 150m/min | 150m/min |
| GSM | 10-180gam | 10-180gsm | 10-180gsm |
| Capactiy | 4T/Day | 7-8T/Day | 9-10T/Day |
| Embossing Pattern | Diamond, oval, cross or line | Diamond, oval, cross or line | Diamond, oval, cross or line |
- Description of Nonwoven machine
- Specifications
- Applications
- Advantage
Description of Nonwoven machine
This polypropylene(pp) spunbond nonwoven production line has advantages of superior performance, beautiful color, and good quality.
It can form a fibre web symmetrically and is complete in types. It can also add recycled material and stuffing to reduce the cost of products.
Specifications
| High speed and Multifunction SSS spunbonded nonwoven machine | ||||
| SSS(Product width) | Equipment Size | Speed | Gram Weight | Yield (according to 20g/m2) |
| 1600mm | 31*13*10m | 450m/min | 10-150g/m2 | 12-13T/Days |
| 2400mm | 32*14*10m | 24-25T/Days | ||
| 3200mm | 34*15*10m | 28-30T/ Days | ||
| The configuration of machines could be CUSTOMIZED as your needs! | ||||
Process flow
Feeding→Extrusion Melting→filtering→metering→spinning→Cooling→Stretching→Web spreading→Thermal bonding→slitting→collecting
Nonwoven machine is called nonwoven equipment or spunbonded nonwoven production line. Raw materials are blended, melted at high temperature, spinning, backlog, hot-pressed into cloth, winding and slitting into finished products. This is the main function and step of nonwovens production line. This machine includes feeding system, screw extrusion, filter, metering pump, spinning box, cooling system, drawing machine, etc.
Applications
Yanpeng Spunbond Nonwoven production lines are designed and manufactured in following applications.
Such as
● PACKAG: Shopping bag, Rice Packaging, Clothes packaging, etc.
● HYGIENE: Baby and adult diapers, Female hygiene, etc.
● MEDICAL: Surgeon's masks, Disposable garments, etc.
● HOUSEHOLD: Suit Cover, Knitwear Cover, Garderobe Cover, Table Cloth Etc.
Advantage
| Product name: | Production line for PP spunbond Non-woven Fabric . |
| Final products: | PP spun bond Nonwoven Fabric. |
| Width: | 1600-3200MM or Customized |
| Raw material: | Polypropylene. |
| Capacity: | 4-10 Tons/day . |
| Application: | Nonwoven Fabric Disposable . |
| Color: | As customer required . |
| After-sales Service Provided: | Engineers available to service machinery overseas . |
| Certificate: | CE, ISO . |
| Machine Type: | Nonwoven Fabric Production line |
| Condition: | New Automatic . |
| Grade: | Automatic . |
Our team and service
● Quality Control in whole process, provide individual high cost-effective spunbond nonwoven production lines, helping customer cost saving.
● Focus on spunbond nonwoven production line research and development for 16 years. Install and running more than 400 lines all over the world
● Import high precision CNC machine from Japan. The key parts machining in house, ensure to provide high quality machine for each customer
● Over 20 person team for machine after sales service.Ensure the customers can get quickly and professional installation and debugged in time.
