Stable and mature technology SSMMS Spun-Bounded Nonwoven Manufacturing Machine
| Model No. | Gram Weight | Application | Certificate |
| YP-SSMMS-1.6M | 12-70g/m2 | Hygiene: Baby diapers, women's sanitary pads, and adult incontinence products Medical: High level medical protective clothing, surgical gowns, surgical masks | CE, ISO |
| YP-SSMMS-2.4M | 12-70g/m2 | ||
| YP-SSMMS-3.2M | 12-70g/m2 | ||
| Customized | 12-70g/m2 |
- Description of Nonwoven machine
- Specifications
- Applications
- Advantage
Description of Nonwoven machine
Product: PP spunbonded nonwovens
Product width:1600mm (final nonwoven product)
Product gram ：10-100 g/m2
Filament titer: 1.8-2.5 Denier
Production capacity: 10-11T/Day (Based on fabric≥20g/m2 8000 Hrs/Year )
Max. Machinery Speed:400 m/min ;Max. Production Speed :350 m/min
Spunbond die:3 ; meltblown die:2
SSMMS nonwoven production line can also produce SS/SSS PP spunbond fabrics or SSMMS PP spunmelt fabrics to adapt different product applications according to customers’ needs.
Specifications
| Product name: | SSMMS Nonwoven production line |
| Final products: | SSMMS spun bond & melt blown Nonwoven Fabric |
| Width: | 1600-3200MM or Customized |
| Raw material: | Polypropylene |
| Capacity: | 13-30Tons/day |
| Application: | Nonwoven Fabric Disposable |
| Color: | As customer required |
| After-sales Service Provided: | Engineers available to service machinery overseas |
| Certificate: | CE, ISO . |
| Machine Type: | Nonwoven Fabric Production line |
| Condition: | New Automatic |
| Grade: | Automatic |
Feeding→Extrusion Melting→filtering→metering→spinning→Cooling→Stretching
→Web spreading→Thermal bonding→slitting→collecting
Feeding:
Raw material: Polypropylene Raw material
1.During feeding, there should be no hard objects such as metals, and no water to ensure cleanliness. 2. Material shortage: Fan malfunction, filter blockage, pipeline leakage, injection machine malfunction alarm. 3. Suction machine: using a volumetric method, simply input the desired percentage.
2.Function of spinning box:
A insulation function
B serves as the base for spinning components
C ensures that the melt pressure is uniform and the flow rate reaches the spinneret uniformly
Applications
Medical and health field：Operating clothes, bed sheets, operating caps, protective clothing, disinfection bags, masks, diapers, women's sanitary napkins, baby diapers, adult slacks, pet urinals, pet pads non-woven fabrics, facial mask base cloth
Filtration:SSMMS non-woven fabric is used for air filtration applications, including HVAC filters and respirators, due to its excellent filtration efficiency. It is also used in liquid filtration systems, such as water and oil filtration.
Advantage
Q: Is your machine equip with slitting machine ?
A: Yes.Our standard machine equip with separate offline slitting machine.
Q: Can we pay by LC/DP?
A: Yes,we accept payment methods such as T/T L/C、D/P D/A.
Q: What exhibition are you attending?
A: All kind of pack machinery exhibition such as Chinaplas as well as non woven fair all of the world,if you want to know more,please contact with us and share with you more details.
